SMART GRIP

  • Features
  • Dimension
  • Cutting data

line

Workpiece clamping systems for 5-axis machines

  • Less interference and superior accessibility!
  • Off line preparation provides you quick work changing!
  • It clamps a workpiece strongly with minimum clamping length.
Compact
Compact
Quick
Quick
High rigidity
High rigidity

Quick-change type

Reduce your setup/machining time and production cost
>>Details of quick-change type
Quick-change type

Direct-mounting type

Clamping the work-piece with the short-est length from the table!
Providing wider machining area.
>>Details of Direct-mounting type
Direct-mounting type

Dovetail clamping system

It clamps a workpiece strongly with minimum clamping length.
It allows strong work-piece clamping even when there is a limited clamping area when performing simple additional machining (dovetail machining) on the work-piece.
It achieves strong and stable machining during side face machining without any interference, minimal tool holder length and cutting tool projection when using a 5-axis machining center.
Dovetail clamping system
Dovetail clamping system
Cost savings with expensive materials.
It achieves material cost savings because the work-piece clamping area is kept to a minimum thus limiting the amount of work-piece material needed for machining.
Compatible with automatic work-piece changing.
The hydraulic clamping design allows for automated work-piece changing, and makes it possible for you to combine your machining centers with robots to create a fully-automated system.
Available for Fully-automated system

Quick-change type

High Rigidity HSK Interface

We have adopted the world standard HSK-A type, time-proven tool holder shanks for the interface coupling between the work holder and the head.
Superior bending rigidity and positioning accuracy are achieved despite the simple method of changing holders, which makes also automation possible.
High Rigility HSK-Inferface
High Rigility HSK-Inferface

Quick workpiece changing and off-line setup.

Easy work holder changing using just a wrench. Off-line setup is possible, so you can start the next machining quickly when the workpiece is mounted to the work holder in advance.
Quick workpiece changing and off-line setup.

High positioning accuracy

No alignment by experienced workers required.
High positioning accuracy
High positioning accuracy

Direct-mounting type

It clamps a work-piece with the shortest length thanks to direct mounting on the table, and provides a larger machining center machining area.
Direct-mounting type
Direct-mounting type
